Alpine Plug & Play Amp Kit Bundle Upgrade 2 & 4-Door (NON-B&O System) | '21- Current Ford Bronco

Your plug and play bundle is hand assembled in our Frederick, MD facility. Current processing lead times for plug and play bundles from order to ship: 12-15 business days

PLUG AND PLAY:  All of our bundles are pre-wired and completely assembled prior to shipping from our Frederick, Maryland shop. When you get your bundle, your full system is ready to drop into your Bronco!  Simply follow the video which guides you through the plug and play install.



NOTE: The rear MTI enclosures do require minor prep which is covered in the provided installation video.



TESTED AND APPROVED BY TRAIL SEVEN: Our amp kit Bundle upgrade has been installed and tested in our Trail Seven Bronco, and we're pleased to put our stamp of approval on this package!

Alpine S2-A55V 5-Channel Amplifier: Entry-level sound just got elevated with the S2-A55V 5-Channel Amplifier. Its sleek redesign houses an Alpine Class D Amplifier Circuit and is now certified for Hi-Res Audio.

• Hi-Res Audio Certified (Up to 40kHz)
• 5-Channel Amplifier
• Alpine’s Class D Amplifier Circuit
• Two-sided terminal layout
• Built-in Selectable/ Adjustable Crossovers
• Optional Remote Bass Knob Compatible (required RUX-KNOB.2 or RUX-H01, sold separately)

Alpine HDA-V90 5-Channel Amplifier: With the highest quality music streaming available on the market, Alpine Status delivers a superior level of audio performance that will take your music to a whole new level.

• Hi-Res Audio Playback (192kHz/24Bit)
• 5-Channel Amplifier
• High-Efficiency Digital Circuit Design
• Alpine’s Dual Negative Feedback Control Circuit
• High Bandwidth Amplifier
• Alpine’s Premium Class D Circuit Design
• Copper-plated chassis
• Black circuit board
• One-sided terminal layout
• Top panel sound controls
• Quick connect power and speaker terminals
• Optional Remote bass knob compatible (requires RUX-KNOB.2 or RUX-H01, sold separately)

• 2021 - Current Bronco: (NON-B&O) 2 & 4-Door

Alpine V90:

• Dimensions: 11.4375” x 7.5” x 2.125”
• Power Rating: (14.4V, ≤1.0% THD+N)
• Power Output: 75W x 4 + 300W x 1 @ 4Ω, 100W x 4 + 500W x 1 @ 2Ω
• Bridged: 200W x 2 @ 4Ω (ch1/2, ch3/4 only)
• THD+N: 0.02% (10W into 4ohm)
• S/N Ratio: 87dB (1W into 4ohm)
• Frequency response: 8-60kHz (-3dB)
• Damping factor: 500 (ch1/2/3/4), 1000 (subwoofer)
• Selectable input level – HI/LO
• Selectable 2/4/6ch input
• Variable High pass / Low pass crossover
• Variable Subsonic filter (subwoofer)
• Bass EQ (0 to +12dB, Variable)
• Auto-turn on with remote sensing

Alpine A55:

• Dimensions: 11.9” W x 2.25” H x 8.25” D
• Weight: 7 lbs
• Power Rating: 14.4V, < 0.1% THD +N
• Power Output: 40W x 4 + 200W x 1 @ 4Ω, 60W x 4 + 300W x 1 @ 2Ω
• Bridged Power: 120W RMS x 2 @ 4Ω
• S/N Ratio: >83dB
• Frequency Response: 20Hz – 40kHz
• Damping Factor: >100CTA-2006-D Certification

• Amplifier: Alpine V90 or Alpine A55
• Amplifier Bracket: Amp will be mounted
• Audio Control LC5i-Pro: Fully prepped, mounted, and adjusted
• 6CH RCA's: Routed from PAC to amp
• Sub Wire: Fully prepped to amp with subwoofer connection
• Amp Harness: Harness full prepped, mounted to the amp bracket and ready for installation
• Radio T-Harness: Fully prepped and ready for installation
• 4AWG Power Kit: 17' 4awg wire, ground lead
• Fuse and Fuse Bracket: mounted to fuse bracket, fully prepped
